ProFace X Series User Manual
Page | 41 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
6.5.2 Wiegand Output
Menu Name Description
SRB(Security Relay
Box)
When SRB is enabled, the lock is controlled by the SRB to prevent the lock
from being opened due to device removal.
Wiegand Format
Values range from 26 bits, 34 bits, 36 bits, 37 bits, and 50 bits.
Wiegand Output Bits
After choosing the Wiegand format, you can select one of the corresponding
output digits in the Wiegand format
Failed ID
If the verification is failed, the system will send the failed ID to the device and
replace the card number or Personnel ID with the new ones.
Site Code
It is similar to the device ID. The difference is that a site code can be set manually,
and is repeatable in a different device. The valid value ranges from 0 to 256 by
default.
Pulse Width(us)
The time width represents the changes of the quantity of electric charge with
high-frequency capacitance regularly within a specified time.
Pulse Interval(us)
The time interval between pulses.
ID Type
Select between User ID and Access Card.
