Recorder Setting
Menu Item
Options
Default
Value
Illustration
Supported printer
models
/
/
Supported printer models:
HP Dest_Jet P1102
HP Dest_Jet P1108
HP Dest_Jet P1008
HP LaserJet Pro M202n
Built-in print layout
34，34+1,
112
34
Select the lead layout for the
built-in printing
4.2.7 General-Filter Setting
Fig. 4.7 General-Filter setting
Filter setting
Menu Item
Options
Default
Value
Illustration
Baseline
drift（Hz）
OFF、0.01、
0.05、0.3、
0.6
0.6
Select the baseline drift filter (BDR)
frequency. Baseline drift filter rejects most
of the baseline drift interference and makes
the ST segment undistorted. Baseline drift
filtering is not performed when set to [Off].
(This filter is high-pass filtering)
