Specifications
Built-in mic (mono) 1Inputs
XLR/TS inputs (mono) 2
Input and
output
channels
Output Headphones 1
Connectors 2 XLR/TS combo jacks
(Balanced, XLR: 2 HOT)
Input gain No adjustment required (dual A/D converter
circuit used)
Input impedance XLR: 2.3 kΩ
TS: 1 MΩ
Maximum input level XLR: +4 dBu
TS: +10 dBu
Phantom power +48 V (switchable separately for INPUTS A and B)
Equivalent input noise XLR: −120 dBu or less (IHF-A)
TS: −107 dBu or less (IHF-A)
XLR/TS inputs
Frequency response XLR: −0.5/+0.0 dB, 20 Hz – 20 kHz
TS: −0.2/+0.0 dB, 20 Hz – 20 kHz
Directionality Omnidirectional
Input gain No adjustment required (dual A/D converter
circuit used)
Inputs
Built-in mic input
Maximum sound pressure
input
115 dB SPL
Connector 1 stereo 3.5mm mini jack
Output impedance 10 Ω
Output Headphones
Maximum output level 20 mW + 20 mW (into 32Ω load)
Maximum simultaneous
recording tracks
2
Recording format WAV: 48kHz, 32-bit float, mono
Recorder
Recording media Cards compatible with microSDHC specifications
4 GB – 32 GB
Cards compatible with microSDXC specifications
64 GB – 1 TB
Display 2" full-color LCD (240 × 320)
USB Connector USB Type-C
Note: Use a USB cable that supports data
transfer. USB bus power is supported.
98
