Making input settings
Connecting input equipment
Connect mics and guitars, for example.
NOTE
The R4 supports Hi-Z input. Guitars, for example, can be connected directly.
1. Connect the equipment to be recorded to INPUT A or INPUT B.
2. Set the INPUT A/MIC (built-in) switch.
Select whether the input source is the INPUT A jack or the built-in mic.
NOTE
When set to MIC, INPUT A will be shown as “MIC” on the INPUT SELECT Screen.
Selecting tracks for recording
The tracks that record INPUT A and INPUT B can be assigned.
Input Select Screen
❶
Current status of each track
The colors show the current status of each track.
36
