ZXR105900ESeriesCongurationGuide(IPv4Routing)
StepCommandFunction
1ZXR10(config)#routerbgp<as-number>ThisstartsBGPprocessand
speciestheASnumberof
router.
2ZXR10(config-bgp)#bgpconfederationidentifier
<value>
ThissetsconfederationID,
therangeis1-65535.
3ZXR10(config-bgp)#bgpconfederationpeers
<value>[<value>]
ThiscongurestheAS
numberofconfederation
peer.Therangeis1-65535
CongurationExample
AsshowninFigure5-17,useconfederationtoavoidIBGPfullconnectioninAS600.
Figure5-17BGPConfederationCongurationExample
CongurationonS2(ThefollowingcontentomitsthecongurationofportandIGP):
S2(config)#routerbgp65003
S2(config-bgp)#bgpconfederationidentifier600
S2(config-bgp)#nosynchronization
S2(config-bgp)#bgpconfederationpeers6500165002
S2(config-bgp)#neighbor172.16.0.2remote-as65001
S2(config-bgp)#neighbor172.16.0.2activate
S2(config-bgp)#neighbor192.168.1.10remote-as65003
S2(config-bgp)#neighbor192.168.1.10activate
S2(config-bgp)#neighbor192.168.1.1remote-as65001
S2(config-bgp)#neighbor192.168.1.1activate
S2(config-bgp)#neighbor172.16.2.2remote-as500
