ZXR105900ESeriesCongurationGuide(IPv4Routing)
RouterIDsarelistedbelow.
DeviceRouterID
S11.1.1.2
S21.1.1.3
S31.1.1.4
Figure3-8RouteAggregationwithRouteRedistributionCongurationExample
RunthefollowingcommandsonS1:
S1(config)#interfaceloopback1
S1(config-if-loopback1)#ipadderss1.1.1.2255.255.255.255
S1(config-if-loopback1)#exit
S1(config)#interfacevlan10
S1(config-if-vlan10)#ipaddress30.0.0.2255.255.255.252
S1(config-if-vlan10)#exit
S1(config)#interfacevlan20
S1(config-if-vlan20)#ipaddress2.2.2.5255.255.255.252
S1(config-if-vlan20)#exit
S1(config)#interfacevlan30
S1(config-if-vlan30)#ipaddress2.2.2.1255.255.255.252
S1(config-if-vlan30)#exit
S1(config)#routerospf1
S1(config-ospf-1)#router-id1.1.1.2
S1(config-ospf-1)#network30.0.0.00.0.0.3area1
S1(config-ospf-1)#redistributeconnected
S1(config-ospf-1)#summary-address2.2.2.0255.255.255.248
S1(config-ospf-1)#exit
RunthefollowingcommandsonS2:
S2(config)#interfaceloopback1
S2(config-if-loopback1)#ipadderss1.1.1.3255.255.255.255
S2(config-if-loopback1)#exit
