Chapter3OSPFConguration
Figure3-10OSPFRedistributionRouteCongurationExample
1.EstablishOSPFneighborhoodbetweenS1andS2.
RunthefollowingcommandsonS1:
S1(config)#interfaceloopback1
S1(config-if-loopback1)#ipadderss1.1.1.2255.255.255.255
S1(config-if-loopback1)#exit
S1(config)#interfacevlan10
S1(config-if-vlan10)#ipaddress30.0.0.1255.255.255.252
S1(config-if-vlan10)#exit
S1(config)#routerospf1
S1(config-ospf-1)#router-id1.1.1.2
S1(config-ospf-1)#network30.0.0.00.0.0.3area0
S1(config-ospf-1)#exit
RunthefollowingcommandsonS2:
S2(config)#interfaceloopback1
S2(config-if-loopback1)#ipadderss1.1.1.3255.255.255.255
S2(config-if-loopback1)#exit
S2(config)#interfacevlan10
S2(config-if-vlan10)#ipaddress30.0.0.2255.255.255.252
S2(config-if-vlan10)#exit
S2(config)#routerospf1
S2(config-ospf-1)#router-id1.1.1.2
S2(config-ospf-1)#network30.0.0.00.0.0.3area0
S2(config-ospf-1)#exit
2.RuntheRIPprotocolonS1andS3.
RunthefollowingcommandsonS1:
S1(config)#interfacevlan20
S1(config-if-vlan20)#ipaddress30.0.1.1255.255.255.252
S1(config-if-vlan20)#exit
S1(config)#routerrip
S1(config-rip)#network30.0.1.00.0.0.255
S1(config-rip)#exit
RunthefollowingcommandsonS3:
S3(config)#interfacevlan10
S3(config-if-vlan10)#ipaddress30.0.1.2255.255.255.252
S3(config-if-vlan10)#exit
3-31
