P-660HW-T v2 User’s Guide

122 Chapter 7 LAN Setup

Figure 68 Physical Network & Partitioned Logical Networks

To change your ZyXEL Device’s IP alias settings, click Network > LAN > IP Alias. The

screen appears as shown.

Figure 69 LAN IP Alias

The following table describes the labels in this screen.

Table 39 LAN IP Alias

LABEL DESCRIPTION

IP Alias 1, 2 Select the check box to configure another LAN network for the ZyXEL Device.

IP Address Enter the IP address of your ZyXEL Device in dotted decimal notation.

Alternatively, click the right mouse button to copy and/or paste the IP address.

IP Subnet Mask Your ZyXEL Device will automatically calculate the subnet mask based on the IP

address that you assign. Unless you are implementing subnetting, use the subnet

mask computed by the ZyXEL Device.
