P-660HW-T v2 User’s Guide

Chapter 18 Logs 227

Alerts are e-mailed as soon as they happen. Logs may be e-mailed as soon as the log is full.

Selecting many alert and/or log categories (especially Access Control) may result in many e-

mails being sent.

Figure 134 Log Settings

The following table describes the fields in this screen.

Table 88 Log Settings

LABEL DESCRIPTION

E-mail Log Settings

Mail Server Enter the server name or the IP address of the mail server for the e-mail addresses

specified below. If this field is left blank, logs and alert messages will not be sent via

E-mail.

Mail Subject Type a title that you want to be in the subject line of the log e-mail message that the

ZyXEL Device sends. Not all ZyXEL models have this field.
