Chapter 3 Wizard Setup for Internet Access 55

CHAPTER 3

Wizard Setup for Internet Access

This chapter provides information on the Wizard Setup screens for Internet access in the web

configurator.

3.1 Introduction

Use the wizard setup screens to configure your system for Internet access with the information

given to you by your ISP.

Note: See the advanced menu chapters for background information on these fields.

3.2 Internet Access Wizard Setup

1 After you enter the admin password to access the web configurator, select Go to Wizard

setup and click Apply. Otherwise, click the wizard icon ( ) in the top right corner of

the web configurator to display the wizard main screen.

Figure 14 Select a Mode

2 Click INTERNET/WIRELESS SETUP to configure the system for Internet access and

wireless connection.
