P-660HW-T v2 User’s Guide

Chapter 20 Diagnostic 251

CHAPTER 20

Diagnostic

These read-only screens display information to help you identify problems with the ZyXEL

Device.

20.1 General Diagnostic

Click Maintenance > Diagnostic to open the screen shown next.

Figure 145 Diagnostic: General

The following table describes the fields in this screen.

Table 111 Diagnostic: General

LABEL DESCRIPTION

TCP/IP

Address

Type the IP address of a computer that you want to ping in order to test a connection.

Ping Click this button to ping the IP address that you entered.
