P-660HW-T v2 User’s Guide

Appendix J Splitters and Microfilters 319

ZyXEL Device With ISDN

This section relates to people who use their ZyXEL Device with ADSL over ISDN (digital

telephone service) only. The following is an example installation for the ZyXEL Device with

ISDN.

Figure 181 ZyXEL Device with ISDN
