MANUGENX5 - Version 1.01 24.03.2021
© 2021 0N3 s.r.l. - Subject to change without notice
11
2.3.1 Pairing Lamp
The functions of the pairing lamp are:
• Support to the pairing procedure for the identication of the Base Station
• Verication of the pairing status of the Base Station
Pairing Lamp Status Description
ON PAIRED
OFF UNPAIRED
BLINK LINK LOSS
In addition to the pairing lamp, the status of the security Safety Link is indicated by a local LED of the Base Station.
The positioning of the pairing lamp must ensure an easy association between the lamp and the machine, as well as
facilitate its display at a distance for the implementation of the pairing procedure.
CAUTION!
• If a Base Station, paired with a Wireless Handheld, is subjected to a power cycle, the link status is not
restored automatically, but the event is reported by the flashing status of the pairing lamp.
2.3.2 Auxiliary Unpairing Input
The auxiliary unpairing input can be used as an alternative recovery procedure to reset the state of Base Station to IDLE
when the device is in SAFE State.
