6.2 Technical data
System Resources
CPU i.MX6UL ARM Cortex A7 - 528 MHz
Operating System Linux 4.14
Flash 4 GB
RAM 512 MB
FRAM 32Kbytes
Real Time Clock, RTC Back-up Yes, rechargeable Lithium battery (not user-replaceable)
Buzzer Yes
Sensors Temperature (internal)
Safety Outputs
Emergency Stop (2+2 relay contacts NO)
Enabling Device (2+2 relay contacts NO)
Digital I/O 1DI, 2DO Safety Auxiliary functions
Interface
Wireless IEEE Std 802.11a/b/g/n (Safety Link)
Ethernet Port 2 (port 0 - 10/100, port 1 - 10/100)
USB Port 1 (Host v. 2.0, max. 500 mA)
Serial Port 1 (RS232/422/485, sw programmable)
SD Card Yes
Expansion 1 slot for plug-in modules
Ratings
Power Supply 24 Vdc (10 to 32 Vdc)
Current Consumption 0,4 A max. at 24 Vdc
Input Protection Electronic
Environment Conditions
Operating Temperature +5 to +45°C
Storage Temperature -20 to +70°C
Operating / Storage Humidity 5-85% RH, non condensing
Protection Class IP20 (not UL evaluated)
Dimensions and Weights
Faceplate LxH 45x134 mm
Depth D+T 102 mm
Weight Approx 0.65 Kg
Installation DIN Rail (TS35)
