2 Safety Link
Safety Link is a Wi-Fi point-to-point connection between a Wireless Handheld and a Base Station.
The same Wi-Fi link is used to exchange Safety and Application data.
2.1 Network conguration
The Wi-Fi link is based on a Private Network where only two devices can be connected at a time: Base Station and
Wireless Handheld.
Network Conguration
Band 2.4GHz / 5GHz, user congurable
Channel Manual selection
SSID Fixed
Password Yes, user congurable
For all details regarding how to setup Network Conguration refer to JMobile Studio User Manual.
2.2 Network SSID
The Network SSID is xed and based on Base Station Unique Identication (SAFETY UID), hardcoded in the device.
User can get Base Station SAFETY UID using System Settings (refer to JMobile Studio User Manual for details) or from
device label.
