0N3 X5 System User Manual

MANUGENX5 - Version 1.01 24.03.2021
© 2021 0N3 s.r.l. - Subject to change without notice
41
7.2 Technical Data
Ratings
Power Supply
24V# ± 25 % Supplied by a SELV (Class 2 according to UL Standards) or
PELV Power Supply
Voltage Output 5V ± 10 %
Power Consumption 0,9 A (max) @ 24V
Protection Type Voltage Input Protection from polarity inversion, over-voltage and under-voltage
Current Input Protection from overload current
Voltage Output Internally regulated
Environment Conditions
Operating Temp +5 to +45°C
Storage Temp -20 to +70°C
Operating / Storage Humidity 5-95% RH, non condensing
Protection Class IP64 (not UL evaluated)
Flame resistant Fulls UL 94V-0: HB 1/16”
Dimensions and Weights
Faceplate LxH 213x113 mm
Depth D+T 89 mm
Weight Approx 0.4 Kg
