MANUGENX5 - Version 1.01 24.03.2021

5.4 Status Indicators

There are two bi-colours LED.

LED1:

Colour Status Description

RED OFF

Wireless Handheld not paired /

Safety Link Loss

RED ON Wireless Handheld paired

GREEN OFF Battery charging OFF

GREEN BLINKING Battery charging COMPLETED

GREEN ON Battery charging ON

LED 2:

Colour Status Description

- - -

RED ON CPU Error

- - -

GREEN ON CPU Run



CAUTION!

• In case of errors contact supplier.

5.5 ON/OFF keys

To switch on or off the Wireless Handheld press the F2 and F5 keys simultaneously for a few seconds. The boot of the

system is indicated by the red and the green indicators switching on in sequence.

Before making the rst power is recommended to run a complete cycle of battery charge.
