MANUGENX5 - Version 1.01 24.03.2021

3.4.1 Wireless Handheld

Event

Safety FSM OFF ON PAIR UNPAIR LINK-LOSS LINK-REC PAIR-LOSS FAIL

OFF - IDLE - - - - - -

IDLE OFF - RUN - - - - EMG

RUN OFF - - IDLE SAFE - P - SAFE EMG

SAFE OFF - - IDLE - - - EMG

SAFE - P OFF - - IDLE - RUN SAFE EMG

EMG OFF - - - - - - -

3.4.2 Base Station

Event

Safety FSM OFF ON PAIR UNPAIR AUX-REC LINK-LOSS LINK-REC PAIR-LOSS FAIL

OFF -

IDLE

SAFE*

- - - - - - -

IDLE OFF - RUN - - - - - EMG

RUN OFF - - IDLE - SAFE - P - SAFE EMG

SAFE OFF - RUN - IDLE - - - EMG

SAFE - P OFF - - - IDLE - RUN SAFE EMG

EMG OFF - - - - - - - -

* When powered up, the device enters Safe State if previously switched off in Safe State
