0N3 X5 System User Manual

MANUGENX5 - Version 1.01 24.03.2021
© 2021 0N3 s.r.l. - Subject to change without notice
27
5.2 Technical data
System Resources
Display - Colours 5” TFT LED - 64K colours
Resolution 480x272
Brightness 300 Cd/m² typ.
Dimming Yes
Touchscreen Resistive
CPU i.MX6UL ARM Cortex A7 - 528 MHz
Operating System Linux 4.14
Flash 4 GB
RAM 512 MB
Real Time Clock, RTC Back-up Yes, rechargeable Lithium battery (not user-replaceable)
Handwheel Yes
Potentiometer 2
Selector 16 positions Rotary Switch
Emergency Stop Button Yes, illuminated
Enabling Button 3 positions
Status Indicators 2 bi-colour LED
Keys 19 user-programmable
Sensors 3-axis Accelerometer, Temperature (internal)
Buzzer, Vibrator Yes
Interface
Wireless IEEE Std 802.11a/b/g/n
USB 2 Host V2.0, 250mA max
NFC Yes
Ratings
Power Supply Rechargeable Battery BATT3V74A401
Battery capacity 4400 mAh (6h of autonomy typ.)
Charging Station Yes
Environment Conditions
Operating Temperature +5 to +45°C
Storage Temperature -20 to +70°C
Operating / Storage Humidity 5-85% RH, non condensing
Protection Class IP64 (not UL evaluated)
Dimensions and Weights
Faceplate LxH 220x144 mm
Depth D+T 63 mm
Weight Approx 0.8 Kg
