MANUGENX5 - Version 1.01 24.03.2021
© 2021 0N3 s.r
.l. - Subject to change without notice
53
8.3.6
X8 Serial Port
RS-422, RS-485
Pin
Description
1
CHB-
2
CHA-
3
CHB+
4
CH
A+
5
+5V Output at 100 mA max.
6
GND
7
8
SHIELD
RS-232
Pin
Description
1
RX
2
TX
3
CTS
4
RTS
5
+5V Output at 100 mA max.
6
GND
7
8
SHIELD
T
o operate in RS-485 pins 1-2 and 4-3 must be connected externally
.
52
54
Table of Contents
Default Chapter
3
Table of Contents
3
Introduction
5
Safety Notices
5
Safety Guidelines
6
1 Overview
8
2 Safety Link
9
Network Configuration
9
Network SSID
9
Pairing and Unpairing Procedure with Pairingapp
10
Pairing Lamp
11
Auxiliary Unpairing Input
11
Add a New Base Station
12
Wi-Fi Connection
12
Pairing Procedure
12
Unpairing - Delete Base Station
13
Unpairing Procedure
13
3 Safety Controls
14
Emergency Stop Button
14
Enabling Button
15
Selector
18
Safety State Diagram
19
Wireless Handheld
20
Base Station
20
Safety Outputs
21
Safety Reaction Time
22
4 Safety Specifications
23
Safety Parameters
23
General Safety Parameters
23
Safety Functions Parameters
23
Proof Test Frequency
24
Lifetime
24
5 Wireless Handheld
25
Overview
25
Technical Data
27
Handheld Device Chemical Resistance
28
Test Results
29
Status Indicators
31
ON/OFF Keys
31
Input Devices
32
Potentiometers
32
Handwheel
32
Keypad
32
Battery
33
Battery Disposal
33
Mechanical Dimensions
34
Maintenance
34
Product Identification
34
6 Base Station
35
Overview
35
Technical Data
36
Status Indicators
37
Power Supply
37
Mechanical Dimensions
38
Product Identification
38
Maintenance
39
7 Charging Station
40
Overview
40
Technical Data
41
Status Indicators
42
Mechanical Dimensions
43
Product Identification
44
8 Installation Guidelines
45
Installation
45
Configuration and Programming
46
Base Station Connectors and Cables
47
General Connection Diagram
48
X1 Power Supply
49
X5 Auxiliary I/O
50
X6 Safety Outputs
51
X7 Selector Outputs
52
X8 Serial Port
53
9 Environmentally-Friendly Disposal
54
10 Standards and Certifications
55
EC Directives
55
International Standards
56
11 Special Instruction for Use
58
12 Unpacking and Packing Instructions
59
