PRINT PAD PLATE LEVELING INSTRUCTIONS
27
Your print pad pad may become un-leveled when transporting your Cube, If this occurs, please follow these instructions to level your print
pad pad for optimum creation experience.
A
The print pad pad can be leveled with the two adjusting bolts located underneath the front and back of the pad.
• Press the power button on the Cube control panel.
• Ensure print pad is properly installed on print pad pad.
• Finger tap “SETUP” on the touchscreen and scroll through the menu until “LEVEL PLATE” appears. Press LEVEL
PLATE; the print pad will move up to print jet tip.
• Using the Up arrow, raise the print pad to the print jet tip until the tip is near the print pad but not touching it.
Front Knob Bolt
Rear Knob Bolt
B
C
