3D Systems Cube 2nd Generation - Print Pad Installation; Setting Print Jet Gap

36
18
SETTING PRINT JET GAP
When the Cube is operating, the print tip on the print jet nozzle becomes hot; avoid touching
this area until it has cooled down.
Theprinttipmustbesettothecorrectdistancebetweentheprinttipandtheprintpadtoensuretherstprintedlayersticks
properly.
1. Finger tap “Set Up” on the touchscreen and press “Next” until “Set Gap” appears.
1. Place print pad magnetic strip onto the magnetic strip on print plate.
17
PRINT PAD INSTALLATION
Tap Here
Rough side of print pad
is facing up
