ROLL SIDE TO SIDE
Turn front adjusting knob bolt clockwise to bring front of pad up.
Turn adjusting knob bolt clockwise to bring right side of
pad down.
If the gap between the print pad and print jet tip is at the right or left side, adjust the pad using the rear adjusting knob bolt.
EXAMPLE:
• If the pad needs to be moved up, turn thea front djusting knob bolt clockwise to loosen and then turn the rear adjusting knob
bolt clockwise. To move the pad down, turn the rear adjusting knob bolt counterclockwise.
• While adjusting, slide the paper between the print jet tip and print pad where the adjustment was needed; the paper should
slide back and forth with no resistance. If resistance is felt, the pad is too high. Please repeat the adjustment.
• Once adjustments are made, tighten the adjusting knob bolts.
If the gap appears on the side of print pad, the
pad is too low and will need to be moved up.
