A10 Thunder Series 930 Installation Guide
Installation
Document No.: TH-930-001 - 1/26/2015 | page 12
Table 1 describes the LED status indicators.
TABLE 1 LED Status Indicators
Installation
Table 2 describes the minimum requirements for your equipment rack. Verify these specifications against your equipment
prior to installing the chassis.
TABLE 2 Equipment Rack Specifications and Part Numbers
LED Color Status Description
PWR
Green On Power is switched ON
Off No power connected
STAT
Amber Flash Post BIOS
Green Flash System under access
Off No power access
DISK
Amber On SSD under access
Off No Data access
10-Gb Ethernet Ports
(Fiber)
LNK Green Off Link down
On Link up
ACT Green Off Port is not sending or receiving traffic.
Flash Port is sending or receiving traffic.
1-Gb Ethernet Ports
(Fiber)
LNK Green Off Link down
On Link up
ACT Green Off Port is not sending or receiving traffic.
Flash Port is sending or receiving traffic.
1-Gb Ethernet Ports
(Copper)
L/A Green Off Link down
On Link up
Flash Port is sending or receiving traffic.
SP Off Off 10M
Green On 100M
Amber On 1G
Item Rack Mount Kit Sliding Rail Kit
Part Number AXSK-RACK MOUNT-XX30 AXSK-RAILKIT-XX30
Item Description 2 or 4-Post Rack Mount Kit 4-Post Sliding Rail Kit
