A10 Thunder Series 930 Installation Guide
Inserting a Fan Module
Document No.: TH-930-001 - 1/26/2015 | page 26
FIGURE 11 Removing a Fan Module
Inserting a Fan Module
Follow the steps below in order to remove a fan module.
1. Gently push the fan module into the slot.
2. Tighten both screws to secure the fan module..
1. Loosen both screws on the right side of the module.
2. Use this handle to pull the fan module out.
