page 39 | Document No.: TH-930-001 - 1/26/2015
Power Supply Product Specifications
The A10 Thunder Series 930 device is compatible with the power supply units described in this chapter:
600W AC Power Supply Specifications
1100W DC Power Supply Specifications
600W AC Power Supply Specifications
Table 3 lists the specifications for the AC power supply.
TABLE 3 600W - AC Power Supply Specifications
Item Specification
Part Number ASK-PS-020
Chassis compatibility A10 Thunder Series 5430-11, 5330, 4430, 3230, 3430, 3030S, 1030S, 930
Power Supply Output 600W 80 Plus Platinum
Warning Method Power Defective signal delivery warning to the Software. (TTL, Low active).
LED indicators Green Output LED: On when the AC outputs are within the valid range and stable.
AC Input Voltage Range 90 VAC ~ 264 VAC
AC Input Current Nominal input voltage: Min 100 VAC; Nom 230 VAC; Max 230 VAC
Derated input voltage range: 90 VAC ~ 115 VAC
Max input current: 13 Arms
Input Frequency: Min 47 Hz; Nom 50/60 Hz; Max 64 Hz
Turn-on input voltage: 80 VAC ~ 87 VAC
Turn-off input voltage: 75 VAC ~ 85 VDC
Inrush current: 40Ap maximum at any low/high range input voltage.
Reliability and Availability Capable of online insertion and removal (OIR)
Cooling Fan Integrated variable speed
Environmental Conditions Ambient temperature: 32°F to 131°F (0°C to 55°C)
Extended temp range: +113°F to 149°F (+45°C to 65°C)
Storage temperature: -4°F to 158°F (-20°C to 70°C)
Altitude: At elevations greater than 6,000 feet, maximum ambient temperature is
113°F/45°C.
