page 31 | Document No.: TH-930-001 - 1/26/2015
Sliding Rail Kit Installation
This chapter contains instructions for installing the sliding rail kit for your ACOS device.
The following topics are covered:
• Getting Started
• Sliding Rail Kit Installation
Getting Started
This section contains the following topics:
• Rail Kit Contents
• Required Tools
Rail Kit Contents
The rail kit contains the following items. Please verify that all parts are included and are not damaged.
• 2 x adjustable rail assemblies
• 12 x black 4-mm flat-head screws, for attaching the inner rails to the chassis
• 13 x silver M5-thread 7-mm flat-head screws with washers, for attaching the outer rails to the rack.
12 are required and the 13
th
is a spare.
NOTE: Each rail assembly consists of an outer rail, a middle rail, and a removable inner rail.
Required Tools
To install the rail kit, you will need the following tools:
• Anti-static wrist strap and conductive foam pad (recommended)
• #1 Phillips-head screwdriver
• #2 Phillips-head screwdriver
• Hex nut driver
