Page #40 background imageLoading...
Page #40 background image
A10 Thunder Series 930 Installation Guide
1100W DC Power Supply Specifications
Document No.: TH-930-001 - 1/26/2015 | page 40
1100W DC Power Supply Specifications
Table 4 lists the specifications for the DC power supply.
TABLE 4 1100W - DC Power Supply Specifications
Item Specifications
Part Number ASK-PSDC-010
Chassis compatibility A10 Thunder Series 6630, 6435(S), 5630, 5435(S), 5430S, 5430-11, 6430(S), 5330, 4435(S),
4430, 3430, 3230, 3030S, 1030S, 930
Power Supply Output 1100W 80 Plus Platinum.
Warning Method Power Defective signal delivery warning to the Software. (TTL, Low active).
LED indicators Green Output LED: On when the AC outputs are within the valid range and stable.
DC Input Voltage Range 40 VDC ~ 72 VDC.
Use at least a 20-amp fuse for each DC breaker.
DC Input Current Nominal input voltage: Nom 53 VDC.
Max input current: 33 Arms.
Input Frequency: Min 47 Hz; Nom 50/60 Hz; Max 64 Hz.
Turn-on input voltage: Min 42 VDC; Max 45 VDC.
Turn-off input voltage: Min 37 VDC; Max 40 VDC.
Inrush current: 60Ap maximum at any low/high range input voltage.
Reliability and Availability Capable of online insertion and removal (OIR).
Cooling Fan Integrated variable speed.
Environmental Conditions Ambient temperature: 32°F to 131°F (0°C to 55°C).
Extended temp range: +113°F to 149°F (+45°C to 65°C).
Storage temperature: -4°F to 158°F (-20°C to 70°C).
Altitude: At elevations greater than 6,000 feet, maximum ambient temperature is
113°F/45°C.
