Rack Mount Kit Installation
This chapter describes how to use the rack-mount kit to install your ACOS device into an equipment rack. The kit supports
both front mounting or center mounting.
• Front Mount Installation
• Center Mount Installation
NOTE: The following devices are shipped with screws on the side of the chassis, to be used in
conjunction with the new screwless sliding rail kit:
- A10 Thunder Series 5330(S)
- A10 Thunder Series 3430(S)
- A10 Thunder Series 3230(S)
If you are installing the rack mount kit for any of these devices, you must first remove
these pre-installed screws before continuing.
In addition, you must also remove the pre-installed smaller ear brackets used with the
screwless rail kit in order to install the bracket needed for the rack mount kit.
