35
Class Item and Parameter Description
Cp Hi
Upper limit
Cp lo
Lower limit
Refer to
"10-8. Comparator Function"
Displayed when Cp in 0
is selected.
Cp ref
Reference value
Cp lmt
Tolerance
Refer to
"10-8. Comparator Function"
Displayed when Cp in 1
is selected.
0 Key mode
Accepts the PRINT key only when
the display is stable.
1
Auto print mode A
(Reference = zero)
2
Auto print mode B
(Reference = last stable value)
Outputs data when the display is
stable and conditions of
ap-p , ap-b
and the reference value are met.
prt
Data output mode
3
Stream mode /
Interval memory mode
With data 0 , outputs data
continuously; with data 2 , uses
interval memory.
0 Plus only
Displayed value>Reference
1 Minus only
Displayed value<Reference
ap-p
Auto print polarity
2 Both
Regardless of displayed value
0 10 digits
1 100 digits
ap-b
Auto print difference
2 1000 digits
Difference between reference value
and displayed value
0 Not used
1 Stores unit mass in counting mode
2 Stores weighing data
3 Stores calibration data
4 Stores comparator settings
data
Data memory
5 Stores tare value
Related items:
prt, int , d-no , 5-td , info
0 Every measurement
1 2 seconds
2 5 seconds
3 10 seconds
4 30 seconds
5 1 minute
6 2 minute
7 5 minute
int
Interval time
8 10 minute
Interval time in the interval memory
mode when using
prt 3, data 2
0 No output d-no
Data number output
1 Output
Refer to "12. DATA MEMORY"
0
No output
1
Time only
2
Date only
5-td
Time/Date output
3
Time and date
Selects whether or not the time
or date is added to the weighing
data. Refer to "10-7. Clock and
Calendar Function" for details.
0
No output
dout
Data output
5-id
ID number output
1
Output
Selects whether or not the ID
number is output.
: Functions for GX-K series. : Factory settings. Digit is a unit of minimum weighing value.
