20-2. Options and Peripheral Instruments
AD-8121B Printer
Compact dot-matrix printer
Statistical function, clock and calendar function,
interval print function, graphic print function, dump print
mode
5 x 7 dots, 16 characters per line
Print paper (AX-PP143, 45 (W) x 50 (L) mm , ø65 mm)
AC adapter or alkaline battery
Options
Order code Name and description
GX-04K
Comparator Output (Relay/ with a Buzzer) / RS-232C / Current Loop
This option generates a relay output corresponding to HI , OK and
LO in the display.
Current loop and RS-232C can be used at the same time.
For example, a personal computer and an AD-8121B printer can be
used simultaneously.
This option is installed in place of the standard RS-232C serial
interface.
GX-06K
Analog Voltage Output / Current Loop
This option outputs a voltage of 0 to1V (or 0.2 to1V) depending on
the displayed value.
With this option, current loop can be used.
For example, an AD-8121B printer can be used simultaneously
using this option.
This option is installed in place of the standard RS-232C serial
interface. So, RS-232C is not available for use.
GX-07K
Waterproof and Dustproof RS-232C Cable
Length 5m, straight type, D-sub 9pin - D-sub 25pin.
25pin of balance side is only waterproof type.
GXK-012
Animal Weighing Bowl
This bowl can be used to weigh a small animal.
When using this bowl, the weighing range that can be used is an
approximately 1.5 kg less than the weighing capacity.
Note When option GX-04K or GX-06K is installed in the balance, the balance does not
comply with IP-65 (waterproof and dustproof).
