Title block and end block
When weight values are recorded as GLP data, a "Title block" is inserted at the beginning
and an "End block" is inserted at the end of a group of weight values in the GLP report.
Notes
To output the report to an AD-8121B , use MODE 3 of the AD-8121B.
If the data memory function is used, the "Title block" and "End block" can not be output.
Operation
Step 1 With the weighing data displayed, press and hold the PRINT key, until 5tart
is displayed, then release the key. The "Title block" is output.
Step 2 The weighing data is output according to the parameter setting of the data output
mode (prt) of the function table.
Step 3 Press and hold the
PRINT key until recend is displayed, then release the key.
The "End block" is output.
Setting of "info 1" Setting of "info 2"
AD-8121 printer format General format
Space, ASCII 20h
<TERM> Terminator, CR , LF or CR
CR Carriage return, ASCII 0Dh
LF Line feed, ASCII 0Ah
-----------A-&-D
MODEL-----GX-30K
S/N-----01234567
ID-------ABCDEFG
DATE--2004/12/31
START
TIME----09:30:00
WT---+12345.6--g
WT---+12346.1--g
WT---+12346.2--g
WT---+12346.3--g
WT---+12345.1--g
WT---+12345.3--g
WT---+12347.1--g
WT---+12346.4--g
END
TIME----10:40:15
SIGNATURE
---------------
~~~~~~~~~~~A~&~D <TERM>
MODEL~~~~~GX-30K
<TERM>
S/N~~~~~01234567
<TERM>
ID~~~~~~~ABCDEFG
<TERM>
DATE
<TERM>
~~~~~~2004/12/31
<TERM>
START
<TERM>
TIME
<TERM>
~~~~~~~~09:30:00
<TERM>
<TERM>
WT~~~+12345.6~~g
<TERM>
WT~~~+12346.1~~g
<TERM>
WT~~~+12346.2~~g
WT~~~+12346.3~~g
WT~~~+12345.1~~g
<TERM>
WT~~~+12345.3~~g
<TERM>
WT~~~+12347.1~~g
<TERM>
WT~~~+12346.4~~g
<TERM>
<TERM>
END
<TERM>
TIME
<TERM>
~~~~~~~~10:40:15
<TERM>
SIGNATURE
<TERM>
<TERM>
<TERM>
----------------
<TERM>
<TERM>
<TERM>
Title block
Manufacturer
Model
Serial number
ID number
Date
Time
Weighing data
Time
Signature
End block
