Procedure
Step 1. Open the battery cover.
Step 2. Remove used batteries.
Step 3. Refer to the direction
symbol (
) inside of
the battery compartment.
Insert two new batteries in
the proper "+" and "-"
direction.
Push the spring terminal
using the "-" terminal of
the battery.
Step 4. Insert the battery by
pushing the "+" terminal.
Step 5. Insert the second battery
using the same method.
Step 6. Close the battery cover.
Keep batteries and the battery cover away from infants and
children with reach, to prevent accidental swallowing or other
accidents.
Use standard AA batteries. Do not use an inflated battery
rechargeable battery, or one that wrapped in tape. It may
become difficult to open the cover.
Step 1. Open.
Step 6. Close.
Install batteries.
Step 2. Remove batteries.
Step 4. Insert.
Step 3. Push spring terminal.
