75
To start data communication with dedicated peripheral
Step 1. Connect the micro USB cable between
the recorder and
dedicated peripheral .
Step 2. The buzzer will sound and
will display on the LCD panel.
The state of data communication
enters standby mode.
Step 3. Carry out analysis using the
dedicated peripheral . The state of
data communication only enters
active online mode during USB
communication.
To stop data communication with dedicated peripheral
Step 1. Remove the cable in the standby mode.
Active
online mode
Connect the micro USB
Pi
Standby
mode
