Aastra NeXspan C User Manual

Page 138 01/2007 AMT/PTD/PBX/0020/2/4/EN
Wiring REP96 repeater synchronization
Description of REP 96
Up to four base stations may be connected per repeater output and from one to four repeaters
may be connected to the master base station.
Figure 7-3: Wiring REP96 repeater synchronization
Sync
17 to 24
Sync
16 to 19
Sync
1 to 8
REPEATER REP 96
Power supply LED
21-point
female
connector
N4
21-point
female
connector
N3
21-point
female
connector
N2
21-point
female
connector
N1
syn-E17
Gray
syn+E23
Gray
syn+E22
Red
syn+E21
Black
syn+E20
Brown
syn+E19
Yellow
syn+E18
Blue
syn+E17
White
syn-E18
Transparent
syn-E19
Gray
syn-E20
Transparent
syn-E21
Gray
syn-E22
Transparent
syn-E23
Gray
syn-E24
White
syn-E24
Transparent
syn + M
White
syn - M
Transparent
48PT Blue
48MT Gray
48V bat+ Blue
48V bat- Gray
Master sync
input
