10.10 Declare the base stations
The MMC XBORFA, Object "RadSta", is used to declare the base stations.
• The fields "TS Frame assignment" and "Freq. assignment" must not be changed (both at 1).
• The field "Anten. choice" must be "Automatic" if the base station has no external antenna.
• The field "Inscript. Radio Stat." must be at "yes" when the system starts up. It must be set to
"no" if there are no mobiles to be registered.
• The field "Type of RadSt" must be set to BIT_M if you are working with 2 pairs (one transmit
pair and one receive pair).
• A base station must be declared 4-channel.
• You can check that the base stations have been put in service via the MMC XBORFA, object
"RadSta", action "Display", RadStations Access mode "Trunk Grp".
TRUNK GROUP AND TRUNKS
Obj.=RadSta Action=Display
RadStations Access mode=BOARD
------------------------------- RADIO STATIONS ACCESS --------------------------
CCU=3. Board type=LDS Number=2 Acces.=1.
------------------------------- CHARACTERISTICS --------------------------
Radst=4-chan Radio station no=0. Ident. RadSt =14
Trunk Gp=0. Access status=IN SERVICE Bus=short
TS Frame assignment=111111111111 Freq. assignment=1111111111
11--------->0 9------->0
Anten. choice= Automatic Inscript. Radio Stat.=YES
Type of RadSt= BIT_M Distance master RadSt=0 to 100m
TRUNK GROUP AND TRUNKS
Obj.=RadSta Action=Display
RadStations Access mode=TRUNK GRP
------------------------------ TRUNK GROUP ACCESS --------------------------
CCU=3. Trunk Gp=0.
------------------------------- LIST OF RADIO BASE STATIONS ---------------------
-----
Board type=LDS
Nr=2. Access=1. Record=YES TS frame=111111111111 Frequenc.=1111111111
Status=FREE Type=External Anten. choice=Automatic Dist.Mast.RS=0 to 100m
Bus=Short Nr=0 Ident. RadSt =14 RadSt=LDS 2 chan.
Nr=.. Access=.. Record=NO TS frame=000000000000 Frequenc.=0000000000
Status=--- Type=Slave Anten. choice=Automatic Dist.Mast.RS=0 to 100m
Bus=Short Nr= Ident. RadSt =.. RadSt=???
Nr=.. Access=.. Record=NO TS frame=000000000000 Frequenc.=0000000000
Status=--- Type=Slave Anten. choice=Automatic Dist.Mast.RS=0 to 100m
Bus=Short Nr= Ident. RadSt =.. RadSt=???
Nr=.. Access=.. Record=NO TS frame=000000000000 Frequenc.=0000000000
Status=--- Type=Slave Anten. choice=Automatic Dist.Mast.RS=0 to 100m
Bus=Short Nr= Ident. RadSt =.. RadSt=???
Press RETURN to go to next page Page No=1 Number of pages=1
-------------------------- THE BALANCE OF RADIO STATIONS STATUS -----------------
----
Nbr. of RadStation=1.. Free=1.. Busy=0.. Out of serv.=0..
Loading=0..
