Page 50 01/2007 AMT/PTD/PBX/0020/2/4/EN
• XX: RPN (radio part number)
Indicates the number of base station used by the mobile
• F: Frequency
Indicates the frequency used by the mobile (0 …. 9)
• S: Slot number
Indicates the slot number used by the mobile ( 0…….b)
• QQ: Quality
Indicates the CRC value (value 40h if there is no degradation, 39h if HO request)
• RR: RSSI
Radio level (Value between 35h and 60h for a Max. signal).
• BSI: Blind Slot Information
12 bits field: 1 bit/slot (1: free, 0: busy)
• AAAA: alarm counter (in alarm mode)
alarm counter (in alarm mode)
• C1C1/R1R1: RPN and RSSI
Indicates best available base station for handover in cell XX
• C2C2/R2R2: RPN and RSSI
Indicates second best available base station for handover in cell XX
• C2C2/R2R2+:
Indicates that on the next page there are more than 3 base stations in cell XX
Use the key to move from one screen to another
•or
one arrow indicates that the mobile terminal is in connected mode, two arrows
indicate that the mobile terminal is in a handover phase.
• Indicates that the base station with RPN XX is saturated (4 channels are occupied).
Line 0, comprising 16 characters, is used to display a certain number of statuses:
• A44 0/1:
Indicates whether or not the base station is in recording mode.
