78 266CRH / 266CRT, 266CSH / 266CST MULTIVARIABLE PRESSURE TRANSMITTER | OI/266CXX/MODBUS-EN REV. A
… 9 Diagnosis / error messages
… Error states and alarms
Error code Displayed message Possible cause Recommended measure
F109.003 Process Temperature Sensor
Fail
A/D converter error of the temperature sensor. Check the connection of the temperature electronics.
Temperature electronics must be replaced if the problem
persists.
Wire break of wrong Pt100 connection. Check the Pt100 connections and process conditions.
The reference voltage for the temperature
measurement is not correct.
The PCB for the temperature measurement should be replaced.
The difference between the main channel and the
reference measurement is outside of tolerance.
F110.002 Sensor Temperature Fail Error in the current circuit for scanning the
temperature.
The measuring cell must be replaced.
F112.001 Static Pressure Sensor Fail Error in the current circuit for scanning the static
pressure.
The measuring cell must be replaced.
F114.000 P-dP Sensor Fail Mechanical damage on the measuring cell.
Measuring cell loses filling fluid, diaphragm is
torn, sensor damaged.
The measuring cell must be replaced.
F116.023 Electronic Memory Failure Electronic memory is damaged. The electronics must be replaced.
F118.017 Sensor Memory Fail Measuring cell memory damaged. The measuring cell must be replaced.
F120.016 Sensor Invalid The measuring cell signal is not updated correctly
due to an electronics error, a measuring cell error
or a poorly connected measuring cell cable.
Check the cable connection and replace measuring cell if the
problem persists.
The model / the version of the measuring cell is
no longer compatible with the connected version
of the electronics.
The measuring cell must be replaced.
M014.037 Configuration Error See the operating manual for possible cause of
the error.
Use the Device Type Manager (DTM) to correct the
configuration.
M016.039 PILD-Changed Op. Conditions The process conditions have changed to such an
extent that new settings are required for the
PILD algorithm.
New training is required for this new process condition.
M018.038 PILD Output Both impulse lines between the measuring cell
and the process are either clogged or closed by
valves.
Check valves and impulse line. If required, clean the impulse lines
and start PILD training.
The impulse line between the pressure measuring
cell and the process is either clogged on the high
pressure side or closed by valves.
The impulse line between the pressure measuring
cell and the process is either clogged on the low
pressure side or closed by valves.
One of the impulse lines between the pressure
measuring cell and the process is either clogged
or closed by valves.
