ABB ACS380 User Manual

5
Guidelines for planning the
electrical installation
Contents of this chapter
This chapter contains guidelines for planning the electrical installation of the drive.
Limitation of liability
The installation must always be designed and made according to applicable local laws
and regulations. ABB does not assume any liability whatsoever for any installation which
breaches the local laws and/or other regulations. Furthermore, if the recommendations
given by ABB are not followed, the drive may experience problems that the warranty
does not cover.
Selecting the main supply disconnecting device
You must equip the drive with a main supply disconnecting device which meets the local
safety regulations. You must be able to lock the disconnecting device to the open position
for installation and maintenance work.
Guidelines for planning the electrical installation 49

ABB ACS380 Specifications

General

Mounting	Wall-mounted
Enclosure Class	IP20
Built-in Features	Braking chopper
Communication	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit, ground fault
Operating Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Humidity	5 to 95% relative humidity, non-condensing
Control Method	Scalar control, vector control
