262 Parameters
35
35 Motor thermal
protection
Motor thermal protection settings such as temperature
measurement configuration, load curve definition and
motor fan control configuration.
See also section Motor thermal protection (page 83).
35.01 Motor estimated
temperature
Displays the motor temperature as estimated by the
internal motor thermal protection model (see parameters
35.50…35.55). The unit is selected by parameter 96.16
Unit selection
This parameter is read-only.
-
-60…1000 °C or °F Estimated motor temperature. 1 = 1°
35.02 Measured
temperature 1
Displays the temperature received through the source
defined by parameter 35.11 Temperature 1 source. The
unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, the unit is ohms.
This parameter is read-only.
-
-60…1000 °C,
-76…9032 °F, 0 ohm
or [35.12]ohm
Measured temperature 1. 1 = 1 unit
35.03 Measured
temperature 2
Displays the temperature received through the source
defined by parameter 35.21 Temperature 2 source. The
unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, the unit is ohms.
This parameter is read-only.
-
-60…1000 °C,
-76…9032 °F, 0 ohm
or [35.22]ohm
Measured temperature 2. 1 = 1 unit
35.04 FEX-01/FPTC-01
status word
Displays the status of optional FEX-01/FPTC-01 modules.
The word can be used as the source of eg. external
events.
The modules are activated by parameter 35.30 FEX-
01/FPTC-01 configuration word.
This parameter is read-only.
-
0000h…FFFFh FEX-01/FPTC-01 status word. 1 = 1
No. Name/Value Description Def/
FbEq16
Bit Name Description
0 Module found in slot 1 1 = Yes: An FEX-01/FPTC-01 module has been detected in
slot 1.
1 Fault active in slot 1 1 = Yes: The module in slot 1 has an active fault.
2 Warning active in slot 1 1 = Yes: The module in slot 1 has an active warning.
3 Module found in slot 2 1 = Yes: An FEX-01/FPTC-01 module has been detected in
slot 2.
4 Fault active in slot 2 1 = Yes: The module in slot 2 has an active fault.
5 Warning active in slot 2 1 = Yes: The module in slot 2 has an active warning.
6 Module found in slot 3 1 = Yes: An FEX-01/FPTC-01 module has been detected in
slot 3.
7 Fault active in slot 3 1 = Yes: The module in slot 3 has an active fault.
8 Warning active in slot 3 1 = Yes: The module in slot 3 has an active warning.
9…15 Reserved
