ABB ACS880 PCP User Manual

294 Parameters
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
CW2 16bit Control Word 2 (16 bits) 21
Other Source selection (see Terms and abbreviations on
page 101).
-
…… … …
53.12 FBA A data out12 See parameter 53.01 FBA A data out1. None
54
54 FBA B settings
Fieldbus adapter B configuration.
54.01 FBA B type Displays the type of the connected fieldbus adapter
module.
0 = Module is not found or is not properly connected, or is
disabled by parameter 50.31 FBA B enable; 1 = FPBA;
32 = FCAN; 37 = FDNA; 101 = FCNA, 128 = FENA-11/21;
135 = FECA; 136 = FEPL; 485 = FSCA.
This parameter is read-only.
-
54.02 FBA B Par2 Parameters 54.02…54.26 are adapter module-specific.
For more information, see the documentation of the
fieldbus adapter module. Note that not all of these
parameters are necessarily in use.
-
0…65535 Fieldbus adapter configuration parameter. 1 = 1
…… … …
54.26 FBA B Par26 See parameter 54.02 FBA B Par2.-
0…65535 Fieldbus adapter configuration parameter. 1 = 1
54.27 FBA B par refresh Validates any changed fieldbus adapter module
configuration settings. After refreshing, the value reverts
automatically to Done.
Note: This parameter cannot be changed while the drive is
running.
Done
Done Refreshing done. 0
Refresh Refreshing. 1
54.28 FBA B par table ver Displays the parameter table revision of the fieldbus
adapter module mapping file (stored in the memory of the
drive).
In format axyz, where ax = major table revision number; yz
= minor table revision number.
This parameter is read-only.
-
Parameter table revision of adapter module. -
54.29 FBA B drive type
code
Displays the drive type code in the fieldbus adapter
module mapping file (stored in the memory of the drive).
This parameter is read-only.
-
0…65535 Drive type code stored in the mapping file. 1 = 1
No. Name/Value Description Def/
FbEq16

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
