458 Fieldbus control through the embedded fieldbus interface (EFB)
Discrete inputs (1xxxx reference set)
Discrete inputs are 1-bit read-only values. Status Word bits are exposed with this data
type. The table below summarizes the Modbus discrete inputs (1xxxx reference set).
00035 Reserved 10.99 RO/DIO control word, bit 2
00036 Reserved 10.99 RO/DIO control word, bit 3
00037 Reserved 10.99 RO/DIO control word, bit 4
00038 Reserved 10.99 RO/DIO control word, bit 5
00039 Reserved 10.99 RO/DIO control word, bit 6
00040 Reserved 10.99 RO/DIO control word, bit 7
00041 Reserved 10.99 RO/DIO control word, bit 8
00042 Reserved 10.99 RO/DIO control word, bit 9
Reference ABB drives profile Transparent profile
10001 RDY_ON Status Word bit 0
10002 RDY_RUN Status Word bit 1
10003 RDY_REF Status Word bit 2
10004 TRIPPED Status Word bit 3
10005 OFF_2_STA Status Word bit 4
10006 OFF_3_STA Status Word bit 5
10007 SWC_ON_INHIB Status Word bit 6
10008 ALARM Status Word bit 7
10009 AT_SETPOINT Status Word bit 8
10010 REMOTE Status Word bit 9
10011 ABOVE_LIMIT Status Word bit 10
10012 User-defined (0) Status Word bit 11
10013 User-defined (1) Status Word bit 12
10014 User-defined (2) Status Word bit 13
10015 User-defined (3) Status Word bit 14
10016 Reserved Status Word bit 15
10017 Reserved Status Word bit 16
10018 Reserved Status Word bit 17
10019 Reserved Status Word bit 18
10020 Reserved Status Word bit 19
10021 Reserved Status Word bit 20
10022 Reserved Status Word bit 21
10023 Reserved Status Word bit 22
10024 Reserved Status Word bit 23
Reference ABB drives profile Transparent profile

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
