Fieldbus control through the embedded fieldbus interface (EFB) 449
 Status Word
The table below shows the fieldbus Status Word for the ABB Drives control profile.
The embedded fieldbus interface converts the drive Status Word into this form for the
fieldbus. The upper case boldface text refers to the states shown in State transition
diagram on page 450.
Bit Name Value STATE/Description
0 RDY_ON 1 READY TO SWITCH ON.
0 NOT READY TO SWITCH ON.
1 RDY_RUN 1 READY TO OPERATE.
0 OFF1 ACTIVE.
2 RDY_REF 1 OPERATION ENABLED.
0 OPERATION INHIBITED.
3 TRIPPED 1 FAULT.
0 No fault.
4 OFF_2_STA 1 OFF2 inactive.
0 OFF2 ACTIVE.
5 OFF_3_STA 1 OFF3 inactive.
0 OFF3 ACTIVE.
6SWC_ON_
INHIB
1 SWITCH-ON INHIBITED.
0–
7 ALARM 1 Warning/Alarm.
0 No warning/alarm.
8AT_
SETPOINT
1 OPERATING. Actual value equals Reference = is within
tolerance limits, i.e. in speed control, speed error is 10%
max. of nominal motor speed.
0 Actual value differs from Reference = is outside tolerance
limits.
9 REMOTE 1 Drive control location: REMOTE (EXT1 or EXT2).
0 Drive control location: LOCAL.
10 ABOVE_
LIMIT
1 Actual frequency or speed equals or exceeds supervision
limit (set by drive parameter). Valid in both directions of
rotation.
0 Actual frequency or speed within supervision limit.
11 USER_0 S
12 EXT_RUN_
ENABLE
1 External Run enable signal received.
0 No external Run enable signal received.
13…15 Reserved

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
