140 Parameters
11.60 Freq out 1 at src min Defines the minimum value of frequency output 1. See
diagrams at parameter 11.58 Freq out 1 src min.
0 Hz
0…16000 Hz Minimum value of frequency output 1. 1 = 1 Hz
11.61 Freq out 1 at src max Defines the maximum value of frequency output 1. See
diagrams at parameter 11.58 Freq out 1 src min.
16000 Hz
0…16000 Hz Maximum value of frequency output 1. 1 = 1 Hz
11.81 DIO filter time Defines a filtering time for parameter 11.01 DIO status.
The filtering time will only affect the DIOs that are in input
mode.
10.0 ms
0.3...100 ms Filtering time for 11.01. 10 = 1 ms
12
12 Standard AI
Configuration of standard analog inputs.
12.01 AI tune Triggers the analog input tuning function.
Connect the signal to the input and select the appropriate
tuning function.
No action AI tune is not activated. 0
AI1 min tune Current analog input AI1 signal value is set as minimum
value of AI1 into parameter 12.17 AI1 min. The value
reverts back to No action automatically.
1
AI1 max tune Current analog input AI1 signal value is set as maximum
value of AI1 into parameter 12.18 AI1 max. The value
reverts back to No action automatically
2
AI2 min tune Current analog input AI2 signal value is set as minimum
value of AI2 into parameter 12.27 AI2 min. The value
reverts back to No action automatically
3
AI2 max tune Current analog input AI2 signal value is set as maximum
value of AI2 into parameter 12.28 AI2 max. The value
reverts back to No action automatically
4
12.03 AI supervision
function
Selects how the drive reacts when an analog input signal
moves out of the minimum and/or maximum limits
specified for the input.
The inputs and the limits to be observed are selected by
parameter 12.04 AI supervision selection.
No action
No action No action taken. 0
Fault Drive trips on 80A0 AI supervision.1
Warning Drive generates an A8A0 AI supervision warning. 2
Last speed Drive generates a warning (A8A0 AI supervision) and
freezes the speed (or frequency) to the level the drive was
operating at. The speed/frequency is determined on the
basis of actual speed using 850 ms low-pass filtering.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
3
Speed ref safe Drive generates a warning (A8A0 AI supervision) and sets
the speed to the speed defined by parameter 22.41 Speed
ref safe (or 28.41 Frequency ref safe when frequency
reference is being used).
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
4
No. Name/Value Description Def/
FbEq16
