Additional parameter data 363

Parameter groups 1…9

No. Name Type Range Unit FbEq32

01 Actual values

01.01 Motor speed used Real -30000.00… 30000.00 rpm 100 = 1 rpm

01.02 Motor speed estimated Real -30000.00…30000.00 rpm 100 = 1 rpm

01.03 Motor speed % Real -1000.00...1000.00 % 100 = 1 %

01.04 Encoder 1 speed filtered Real -30000.00…30000.00 rpm 100 = 1 rpm

01.05 Encoder 2 speed filtered Real -30000.00…30000.00 rpm 100 = 1 rpm

01.06 Output frequency Real -500.00…500.00 Hz 100 = 1 Hz

01.07 Motor current Real 0.00…30000.00 A 100 = 1 A

01.10 Motor torque Real -1600.0…1600.0 % 10 = 1%

01.11 DC voltage Real 0.00... 2000.00 V 100 = 1 V

01.13 Output voltage Real 0…2000 V 1 = 1 V

01.14 Output power Real -32768.00…32767.00 kW or

100 = 1 unit

01.15 Output power % of motor

nom

Real -300.00...300.00 % 10 = 1 %

01.17 Motor shaft power Real -32768.00...32767.00 kW or

100 = 1 unit

01.18 Inverter GWh motoring Real 0…32767 GWh 1 = 1 GWh

01.19 Inverter MWh motoring Real 0…1000 MWh 1 = 1 MWh

01.20 Inverter kWh motoring Real 0…1000 kWh 1 = 1 kWh

01.21 U-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.22 V-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.23 W-phase current Real -30000.00 … 30000.00 A 100 = 1 A

01.24 Flux actual % Real 0…200 % 1 = 1%

01.29 Speed change rate Real -15000…15000 rpm/s 1 = 1 rpm/s

01.30 Nominal torque scale Real 0.000…4000000.000 N•m or

lb.ft

1000 = 1 unit

01.31 Ambient temperature Real -40…120 °C or °F 10 = 1 °

01.32 Inverter GWh regenerating Real 0…32767 GWh 1 = 1 GWh

01.33 Inverter MWh

regenerating

Real 0…1000 MWh 1 = 1 MWh

01.34 Inverter kWh regenerating Real 0…1000 kWh 1 = 1 kWh

01.35 Mot - regen energy GWh Real -32768 … 32767 GWh 1 = 1 GWh

01.36 Mot - regen energy MWh Real -1000…1000 MWh 1 = 1 MWh

01.37 Mot - regen energy kWh Real -1000…1000 kWh 1 = 1 kWh

01.61 Abs motor speed used Real 0.00 … 30000.00 rpm 100 = 1 rpm

01.62 Abs motor speed % Real 0.00 … 1000.00 % 100 = 1 rpm

01.63 Abs output frequency Real 0.00 … 500.00 Hz 100 = 1 Hz

01.64 Abs motor torque Real 0.0 … 1600.0 % 10 = 1%

01.65 Abs output power Real 0.00 … 32767.00 kW or

100 = 1 unit

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
