ABB ACS880 PCP User Manual

Additional parameter data 379
21.02 Magnetization time Real 0…10000 ms 1 = 1 ms
21.03 Stop mode List 0…1 - 1 = 1
21.04 Emergency stop mode List 0…2 - 1 = 1
21.05 Emergency stop source Binary
src
--1 = 1
21.06 Zero speed limit Real 0.00 … 30000.00 rpm 100 = 1 rpm
21.07 Zero speed delay Real 0…30000 ms 1 = 1 ms
21.08 DC current control PB 0000b…0011b - 1 = 1
21.09 DC hold speed Real 0.00…1000.00 rpm 100 = 1 rpm
21.10 DC current reference Real 0.0…100.0 % 10 = 1%
21.11 Post magnetization time Real 0…30000 ms 1 = 1 ms
21.12 Continuous magnetization
command
-
21.13 Autophasing mode List 0…2 - 1 = 1
21.18 Auto restart time Real 0.0, 0.1…5.0 s 10 = 1 s
21.19 Scalar start mode List 0…2 - 1 = 1
22 Speed reference selection
22.01 Speed ref unlimited Real -30000.00…30000.00 rpm 100 = 1 rpm
22.11 Speed ref1 source Analog
src
--1 = 1
22.12 Speed ref2 source Analog
src
--1 = 1
22.13 Speed ref1 function List 0…5 - 1 = 1
22.14 Speed ref1/2 selection Binary
src
--1 = 1
22.15 Speed additive 1 source Analog
src
--1 = 1
22.16 Speed share Real -8.000…8.000 - 1000 = 1
22.17 Speed additive 2 source Analog
src
--1 = 1
22.21 Constant speed function PB 0000b…0011b - 1 = 1
22.22 Constant speed sel1 Binary
src
--1 = 1
22.23 Constant speed sel2 Binary
src
--1 = 1
22.24 Constant speed sel3 Binary
src
--1 = 1
22.26 Constant speed 1 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.27 Constant speed 2 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.28 Constant speed 3 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.29 Constant speed 4 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.30 Constant speed 5 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.31 Constant speed 6 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
22.32 Constant speed 7 Real -30000.00 … 30000.00 rpm 100 = 1 rpm
No. Name Type Range Unit FbEq32

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
