SET UP THE CBXI AND CONNECTED FLX MODULES IN A SITE IN CXPROᴴᴰ
On an MS/TP trunk, a CBXi device acts as a Router. Because of this, CBXi controllers are configured in the
Networks section of the Edit Controllers dialog in CXproᴴᴰ’s Configuration utility.
Click the Add button, select the new Network that is created, and click the Edit button:
Set the Controller Type to
CBXi
:
Set the controller Name, Device Instance Number and IP Address : Port (for exporting to ASPECT® and INTEGRA™)
and if the CBX device has one or more FLX modules connected to it, add the same number of entries in the
Modules table:
