High-speed counters,
CL-DC1, CL-DC2
127
1SVC 440 795 M0100
Value range
The counter relay counts between 0 and 32000.
Behaviour when value range is reached
The logic relay is in RUN mode.
The value is retained if the counter reaches 32000. If the
counter counts down and reaches 0, this value is retained.
Parameter display in RUN mode:
Retention
The high-speed counter can be run with the retentive actual
value. You can select the retentive counter relays in the
SYSTEM… r RETENTION… menu. C5 to C7, C8 and C13 to
C16 can be selected.
If a counter relay is retentive, the actual value is retained
when the operating mode changes from RUN to STOP as
well as when the power supply is switched off.
If the logic relay is started in RUN mode, the counter relay
operates with the retentively saved actual value.
Current setpoint, constant (1 250)
# Contact has not switched.
â Contact has switched.
Actual value (877)
C13
H+
S 00950
