From the first contact to the output coil
With the logic relay you work from the input to the output.
The first input contact is
I1.
X Press OK.
The logic relay proposes the first contact
I1 at the cursor
position.
X I flashes and can be changed, for example, to a P for a
pushbutton input using the cursor buttons Í or Ú.
However, nothing needs to be changed at this point.
X Press OK 2 x, to move the cursor across the 1 to the
second contact field.
You could also move the cursor to the next contact field
using the cursor button
í.
X Press OK.
Again, the CL inserts a contact
I1 at the cursor position.
Change the contact number to
I2 so that n/c contact S2 can
be connected to input terminal I2.
X Press OK so that the cursor jumps to the next position and
use cursor buttons Í or Ú to change the number
2.
X Press OK to move the cursor to the third contact field.
You do not need a third relay contact, so you can now wire
the contacts directly up to the coil field.
I1 êê êê êêê
I1 I1 êê êêê
h
Press DEL to delete a contact at the cursor position.
I1-I2 Â
