Wiring with the logic relay
76
1SVC 440 795 M0100
Saving and loading circuit diagrams
The logic relay provides you with two ways of saving circuit
diagrams externally:
• Saving with the memory module
• Saving to a PC running CL-SOFT.
Once they have been saved, programs can be reloaded into
the logic relay, edited and run.
All circuit diagram data is saved in the logic relay. In the
event of a power failure the data will be retained until the
next time it is overwritten or deleted.
Memory module
Each CL-LAS.MD003 memory module contains one circuit
diagram and is inserted in the interface of the logic relay. The
program is stored retentively on the memory module.
The way the memory module works and a description of how
to transfer a program to the module is given in on section
“Memory module”, Page 239.
CL SOFT
CL-SOFT is a PC program with which you can create, store,
test and manage CL circuit diagrams.
h
The circuit diagram display performs two functions:
• In STOP mode it is used to edit the circuit diagram.
• In RUN mode it is used to check the circuit diagram
using the power flow display.
h
MD001 memory modules of the AC010 devices can be
read in CL-LSR/CL-LST. Memory modules MD001 and
MD002 of AC010 devices can be read in the CL-LMR/
CL-LMT.
Only the CL-LAS.MD003 memory module can be write
accessed by CL-LSR/CL-LST and CL-LMR/CL-LMT.
